The Potential of Transparent Wood Biocomposites for Sustainable Acoustics Panel Membrane
Article Sidebar
Main Article Content
Abstract
Acoustic comfort is vital in indoor environments, and the demand for efficient sound-absorbing materials is increasing. While effective, traditional porous materials like rock wool and glass wool pose health risks due to the emission of fine fibers, leading to interest in safer alternatives, such as membrane-based panels. Transparent Wood (TW), a novel material created by removing lignin from wood, offers both sound-absorbing capabilities and environmental benefits. This study aims to evaluate the acoustic performance of TW-based membrane panels by investigating their sound absorption characteristics and the underlying mechanisms of absorption. Maple (Acer laurinum) and mahogany (Swietenia macrophylla) wood veneers were delignified with NaClO2 in an acetate buffer solution and H2O2, followed by polymer impregnation using epoxy resin. The sound absorption capabilities of TW were investigated through morphological analysis using Scanning Electron Microscopy (SEM) and acoustic performance testing via the impedance tube transfer function method. TW membrane panels have the potential to be sound-absorbing materials with absorption rates exceeding 20% at frequencies ranging from 400 to 3150 Hz. The highest absorption occurs at 630 Hz (α = 0.659 for maple wood and 0.603 for mahogany wood) and at 2500 Hz (α = 0.533 for maple wood and 0.548 for mahogany wood). The sound absorption mechanism of TW resembles that of a membrane absorber, in which the air cavity acts as an acoustic spring and the panel acts as the vibrating mass. By understanding the acoustic analysis in this study, it is hoped that TW-based membrane panels can be used as sustainable sound-absorbing materials.
Article Details
This work is licensed under a Creative Commons Attribution 4.0 International License.
Journal of Studies in Science and Engineering is licensed under a Creative Commons Attribution License 4.0 (CC BY-4.0).
References
Y. Bai and H. Jin, "Effects of visual, thermal, and acoustic comfort on the psychological restoration of the older people in a severe cold city," Building and Environment, vol. 239, p. 110402, 2023, doi: https://doi.org/10.1016/j.buildenv.2023.110402.
M. Rocca, F. Di Puccio, P. Forte, and F. Leccese, "Acoustic comfort requirements and classifications: Buildings vs. yachts," Ocean Engineering, vol. 255, p. 111374, 2022, doi: https://doi.org/10.1016/j.oceaneng.2022.111374.
E.-S. Jang, "Sound absorbing properties of selected green material—A review," Forests, vol. 14, no. 7, p. 1366, 2023, doi: https://doi.org/10.3390/f14071366.
U. Berardi and G. Iannace, "Acoustic characterization of natural fibers for sound absorption applications," Building and Environment, vol. 94, pp. 840-852, 2015, doi: https://doi.org/10.1016/j.buildenv.2015.05.029.
H. S. Seddeq, N. Aly, A. Marwa, and M. Elshakankery, "Investigation on sound absorption properties for recycled fibrous materials," Journal of Industrial Textiles, vol. 43, no. 1, pp. 56-73, 2013, doi: https://doi.org/10.1177/1528083712446956.
P. V. Shanbhag, A. K. Guha, and K. K. Sirkar, "Membrane-based integrated absorption− oxidation reactor for destroying VOCs in air," Environmental science & technology, vol. 30, no. 12, pp. 3435-3440, 1996, doi: https://doi.org/10.1021/es950916j.
D. Thapliyal et al., "Natural fibers composites: origin, importance, consumption pattern, and challenges," Journal of Composites Science, vol. 7, no. 12, p. 506, 2023, doi: https://doi.org/10.3390/jcs7120506.
J. P. Arenas and K. Sakagami, "Sustainable acoustic materials," Sustainability, vol. 12, no. 16, p. 6540, 2020, doi: https://doi.org/10.3390/su12166540 .
M. Chutturi et al., "A comprehensive review of the synthesis strategies, properties, and applications of transparent wood as a renewable and sustainable resource," Science of the Total Environment, vol. 864, p. 161067, 2023, doi: https://doi.org/10.1016/j.scitotenv.2022.161067.
J. Gao et al., "Large size translucent wood fiber reinforced PMMA porous composites with excellent thermal, acoustic and energy absorption properties," Composites Communications, vol. 30, p. 101059, 2022, doi: https://doi.org/10.1016/j.coco.2022.101059.
N. Zhen, R.-R. Huang, S.-W. Fan, Y.-F. Wang, and Y.-S. Wang, "Resonance-based acoustic ventilated metamaterials for sound insulation," npj Acoustics, vol. 1, no. 1, p. 7, 2025, doi: https://doi.org/10.1038/s44384-025-00011-y .
M. S. Özer, F. Beyer, and M. E. Altinsoy, "Improving low frequency sound absorption of panel absorbers using point mass," Applied Acoustics, vol. 240, p. 110890, 2025, doi: https://doi.org/10.1016/j.apacoust.2025.110890.
H. Mamtaz, M. H. Fouladi, M. Al-Atabi, and S. Narayana Namasivayam, "Acoustic absorption of natural fiber composites," Journal of Engineering, vol. 2016, no. 1, p. 5836107, 2016, doi: https://doi.org/10.1155/2016/5836107.
S. Torresin, R. Albatici, F. Aletta, F. Babich, T. Oberman, and J. Kang, "Acoustic design criteria in naturally ventilated residential buildings: New research perspectives by applying the indoor soundscape approach," Applied Sciences, vol. 9, no. 24, p. 5401, 2019, doi: https://doi.org/10.3390/app9245401.
H. Liu, X. Xu, V. W. Tam, and P. Mao, "What is the “DNA” of healthy buildings? A critical review and future directions," Renewable and Sustainable Energy Reviews, vol. 183, p. 113460, 2023, doi: https://doi.org/10.1016/j.rser.2023.113460.
L. K. Hendinata, N. A. Siddiq, S. S. Utami, A. I. R. Fikri, M. A. Suprapto, and R. Prilia, "Delignified wood biocomposites as sustainable and transparent materials for passive cooling applications," Wood Material Science & Engineering, vol. 19, no. 2, pp. 291-301, 2024, doi: https://doi.org/10.1080/17480272.2023.2240295.
J. Qin et al., "Optimization of delignification process for efficient preparation of transparent wood with high strength and high transmittance," Vacuum, vol. 158, pp. 158-165, 2018, doi: https://doi.org/10.1016/j.vacuum.2018.09.058.
X. Hu et al., "Fabrication, functionalities and applications of transparent wood: a review," Advanced Functional Materials, vol. 33, no. 37, p. 2303278, 2023, doi: https://doi.org/10.1002/adfm.202303278.
X. Zhao et al., "A scalable high-porosity wood for sound absorption and thermal insulation," Nature Sustainability, vol. 6, no. 3, pp. 306-315, 2023, doi: https://doi.org/10.1038/s41893-022-01035-y.
M. Yang and P. Sheng, "Sound absorption structures: From porous media to acoustic metamaterials," Annual Review of Materials Research, vol. 47, no. 1, pp. 83-114, 2017, doi: https://doi.org/10.1146/annurev-matsci-070616-124032.
M. Mohammadi, M. R. Ishak, M. T. H. Sultan, and E. S. Zainudin, "A Comprehensive Review of Factors Influencing the Sound Absorption Properties of Micro-Perforated Panel Structures," Journal of Vibration Engineering & Technologies, vol. 13, no. 5, p. 319, 2025, doi: https://doi.org/10.1007/s42417-025-01849-y.
T. M. El-Basheer, A. A. El Ebissy, and N. F. Attia, "Fabrication of cost-effective double layers composite for efficient sound-absorbing based on sustainable and flame-retardant jute fabrics," Journal of Industrial Textiles, vol. 51, no. 3_suppl, pp. 4097S-4117S, 2022, doi: https://doi.org/10.1177/15280837221098197.
N. I. Hamdan, M. H. Zainulabidin, and A. S. M. Kassim, "A review on the development of panel and membrane sound absorbers," International Journal of Integrated Engineering, vol. 13, no. 1, pp. 60-74, 2021, doi: https://doi.org/10.30880/ijie.2021.13.01.007.
L. E. Kinsler, A. R. Frey, A. B. Coppens, and J. V. Sanders, Fundamentals of acoustics. John wiley & sons, 2000.
T. Cox and P. d’Antonio, Acoustic absorbers and diffusers: theory, design and application. CRC press, 2016, doi: https://doi.org/10.1201/9781315369211.
L. Pan and F. Martellotta, "A parametric study of the acoustic performance of resonant absorbers made of micro-perforated membranes and perforated panels," Applied Sciences, vol. 10, no. 5, p. 1581, 2020, doi: https://doi.org/10.3390/app10051581.
J. Dessi-Olive and T. Hsu, "A design framework for absorption and diffusion panels with sustainable materials," in INTER-NOISE and NOISE-CON Congress and Conference Proceedings, 2021, vol. 263, no. 4: Institute of Noise Control Engineering, pp. 2207-2218, doi: https://doi.org/10.3397/in-2021-2074.
Y. Wang and P. Mertiny, "Mechanical and Thermal Properties of Epoxy Resin upon Addition of Low-Viscosity Modifier," Polymers, vol. 16, no. 17, p. 2403, 2024, doi: https://doi.org/10.3390/polym16172403.
J. Cha, J. Kim, S. Ryu, and S. H. Hong, "Comparison to mechanical properties of epoxy nanocomposites reinforced by functionalized carbon nanotubes and graphene nanoplatelets," Composites Part B: Engineering, vol. 162, pp. 283-288, 2019, doi: https://doi.org/10.1016/j.compositesb.2018.11.011.
F. L. Dri, L. G. Hector Jr, R. J. Moon, and P. D. Zavattieri, "Anisotropy of the elastic properties of crystalline cellulose Iβ from first principles density functional theory with Van der Waals interactions," Cellulose, vol. 20, no. 6, pp. 2703-2718, 2013, doi: https://doi.org/10.1007/s10570-013-0071-8.
P. Zhang et al., "Sound absorption performance of micro-perforated plate sandwich structure based on triply periodic minimal surface," Journal of Materials Research and Technology, vol. 27, pp. 386-400, 2023, doi: https://doi.org/10.1016/j.jmrt.2023.09.237.
W. Chen, S. Liu, L. Tong, and S. Li, "Design of multi-layered porous fibrous metals for optimal sound absorption in the low frequency range," Theoretical and Applied Mechanics Letters, vol. 6, no. 1, pp. 42-48, 2016, doi: https://doi.org/10.1016/j.taml.2015.12.002.
K. Mahesh and R. Mini, "Theoretical investigation on the acoustic performance of Helmholtz resonator integrated microperforated panel absorber," Applied Acoustics, vol. 178, p. 108012, 2021, doi: https://doi.org/10.1016/j.apacoust.2021.108012.
R. Sailesh, L. Yuvaraj, J. Pitchaimani, M. Doddamani, and L. B. M. Chinnapandi, "Acoustic behaviour of 3D printed bio-degradable micro-perforated panels with varying perforation cross-sections," Applied Acoustics, vol. 174, p. 107769, 2021, doi: https://doi.org/10.1016/j.apacoust.2020.107769.
E.-S. Jang, S.-U. Jo, C.-W. Kang, and H.-J. Park, "Investigating the Sound Absorption Performance of Circular and Slotted Perforated Birch (Betula platyphylla) Plywood as Interior Building Materials," BioResources, vol. 19, no. 1, 2024, doi: https://doi.org/10.15376/biores.19.1.1517-1525.
X. Zhu, Z. Chen, Y. Jiao, and Y. Wang, "Broadening of the sound absorption bandwidth of the perforated panel using a membrane-type resonator," Journal of Vibration and Acoustics, vol. 140, no. 3, p. 031014, 2018, doi: https://doi.org/10.1115/1.4038942.
J. Boulvert et al., "Optimally graded porous material for broadband perfect absorption of sound," Journal of Applied Physics, vol. 126, no. 17, 2019, doi: https://doi.org/10.1063/1.5119715.
